Navigation Lights

Marine navigation lights are coloured electric lights that indicate the size of the vessel and the direction in which it is travelling avoiding collisions at sea and facilitating the navigation. Federal and International regulations require boats to carry lights between sunset and sunrise as well as during conditions of restricted visibility i.e fog or heavy rain. Lalizas navigation lights are approved for power boats or sail boats up to 20m. A variety of different designs, sizes, and finishes are available, offering a multitude of installation options. Depending on the model, navigation lights can be mounted vertically or horizontally on a suitable surface of the boat and they are connected to the central and auxiliary circuit. Navigations lights should not be put under any kind of strain, and should be positioned in such a way to conform to all regulations.

Showing 17–32 of 41 results

  • CYCLIC 12

    0.00฿

    Cyclic 12

    The Cyclic 12 navigation lights are designed for powerboats and sailboats up to 12m length. Their elegant “helmet” styling leaves no sharp edges to cause injury or catch lines. Material: They are made of tough UV stabilized nylon plastic, non magnetic stainless steel electrical contacts and a nitrile water resistant seal to provide reliable long life. Housing: Available in black and white housing. Installation: Vertical mounted. Visible distance: Port – Starboard – Bicolor: 1nm /Stern – Masthead: 2nm Bulb (included): 12V / 10W

    Cyclic 12 Port-Starboard-Bicolor-Stern-Masthead

    Code 30461 30462 30463 30464
    Description Starboard Green 112’5° Port Red 112,5° Stern White 135º Masthead White 225°
    Housing Black

    Cyclic 12 Port-Starboard-Bicolor-Stern-Masthead

    Code 30471 30472 30473 30474
    Description Starboard Green 112,5º Port Red 112,5º Stern White 135º Masthead White 225º
    Housing White
    Read moreDone

  • EMERGENCY LIGHTS

    0.00฿

    Emergency Navigation Lights

    Emergency waterproof navigation lights are ideal for use on small crafts, inflatable boat, kayaks, or as emergency lighting in larger vessels. All around portable Emergency lights can be used when conventional lights are not suitable for the vessel or when they are not operating. They are available with external light reflectors and use standard alkaline batteries (D cell ), giving approx. 9 hours of continuous use. Batteries are not included.

    Code Description
    30001 Green
    30002 Red
    30003 White
    30010 Set

    Read moreDone

  • EYE 7

    0.00฿

    Eye 7

    The Eye 7 series of navigation lights are designed for powerboats up to 7m length. They are waterproof, non corrosion and non magnetic. Material: Nylon fibre mix housing. Shatterproof plexiglas (PMMA) lens. Housing: Available in black, white and chrome housing. Seal: Nitrile water resistant. Installation: The Eye 7 lights are a unique design within the Lalizas range of vertical mount navigation lights. Their special design enables them to be neatly mounted on the boat, both ensuring safety without compromising good looks. They are fitted into the vessel’s bow, not leaving any sharp edges to either spoil the vessel’s lines or cause injuries. They are provided with a two sided adhesive tape and flange, which by sticking it on the surface you know exactly where to open the hole and the flange is already in the correct place. Visible distance: Port – Starboard: 1nm / Stern: 2nm. Contacts: Brass. Bulb (included): 12V / 5W.

    Eye 7 Starboard Green 112,5º Horizontal

    Code 30841 30851 30921
    Housing Black White Chrome

    Eye 7 Port Red 112,5º Horizontal

    Code 30842 30852 30922
    Housing Black White Chrome

    Eye 7 Stern White 135º

    Code 30843 30853
    Housing Black White

    Read moreDone

  • FAROS 7

    0.00฿

    Port- Starboard- Stern- Masthead- Bicolor Lights

    The Faros 7 series of navigation lights, Including masthead, side and stern lights, is ideal mainly for powerboats up to 7m. They are waterproof, non corrosion and non magnetic. Material: Made of nylon fibre mix housing and shatterproof plexiglass (PMMA) lens. Housing: Available in black housing. Seal: Nitrile water resistant. Installation: Vertical & horizontal mounted. They are mounted on the surfaces with wall plugs. Navigation lights with wall plug have the advantage that they are much easier to mount and you only need to open one hole. This range is provided with a two sided adhesive tape and flange, which by sticking it on the surface you know exactly where to open the hole and the flange is already in the correct place. Visible distance: Port – Starboard – Bicolor: 1nm / Stern – Masthead: 2nm. Contacts: Brass. Bulb (included): 12V / 5W

    Instructions:

    1. Remove the protective paper from the self adhesive flange
    2. Attach the flange at the point you want to place the light and open the holes using a drill
    3. Pass the wires through the lower hole and fit the light’s rawl plugs in the side holes
    4. Screw until the rawl plugs are secured
    Code 30864 30865 31051 31052 30861 30862 30863
    Description Masthead White 225° Bi-colour 225° Starboard Green 112,5° Horizontal Port Red 112,5° Horizontal Starboard Green 112,5º Port Red 112,5° Stern White 135°
    Images
    Housing Black



    Read moreDone

  • FOS LED 12

    0.00฿

    Stern Light Side Mount 135°

    Code 71301 71302
    Housing Black White

    →For boats up to 12m (Recreational Crafts)
    →Visible distance: 2 nm
    →12-15 V DC & 0.5W
    →White LED light
    →Vertical Mounted
    →Last for 50.000 hours
    →Waterproof, non-corrosive, non-magnetic

    Included:

    1. Screw DIN7981 / ISO 7049 M3.5x32mm
    2. Wire length 0.6m
    3. Double-side adhesive sticker that can be used as drilling drawing

    *Weight: 65gr/pc

    Read moreDone

  • FOS LED 12

    0.00฿

    Masthead Light 225°

    Code 71303 71304
    Housing Black White

    →For boats up to 12m (Recreational Crafts)
    →Visible distance: 2 nm
    →12-15 V DC & 1W
    →White LED light
    →Vertical Mounted
    →Last for 50.000 hours
    →Waterproof, non-corrosive, non-magnetic

    Included:

    1. Screw DIN7981 / ISO 7049 M3.5x32mm
    2. Wire length 0.6m
    3. Double-side adhesive sticker that can be used as drilling drawing

    *Weight: 150gr/pc

    Read moreDone

  • FOS LED 12

    0.00฿

    Bi-color Light Side Mount

    Code 71305 71306
    Housing Black White

    →For boats up to 12m (Recreational Crafts)
    →Visible distance: 1 nm
    →12-15 V DC & 1W
    →Red & Green LED light
    →Vertical Mounted
    →Last for 50.000 hours
    →Waterproof, non-corrosive, non-magnetic

    Included:

    1. Screw DIN7981 / ISO 7049 M3.5x32mm
    2. Wire length 0.6m
    3. Double-side adhesive sticker that can be used as drilling drawing

    *Weight: 150gr/pc

    Read moreDone

  • FOS LED 12

    0.00฿

    Tricolor Light

    Code 71309 71310
    Housing Black White

    →For boats up to 12m (Recreational Crafts)
    →Visible distance: 1+1+2 nm
    →12-15 V DC & 1,5W
    →Red, Green & White LED light
    →Deck Mounted
    →Last for 50.000 hours
    →Waterproof, non-corrosive, non-magnetic

    Included:

    1. Screw DIN7981 / ISO 7049 M3.5x32mm
    2. Wire length 0.6m
    3. Double-side adhesive sticker that can be used as drilling drawing

    *Weight: 95gr/pc

    Read moreDone

  • FOS LED 12

    0.00฿

    Tricolor & Anchor Light

    Code 71311 71312
    Housing Black White

    →For boats up to 12m (Recreational Crafts)
    →Visible distance: 1 nm
    →12-15 V DC & 0.5W
    →Red & Green LED light
    →Side Mounted
    →Last for 50.000 hours
    →Waterproof, non-corrosive, non-magnetic

    Included:

    1. Screws DIN7981 / ISO 7049 M3.5x32mm
    2. Wire length 0.6m
    3. Double-side adhesive sticker that can be used as drilling drawing

    *Weight: 60gr/pc



    Read moreDone

  • FOS LED 12

    0.00฿

    Stern Light Deck Mount 135°

    Code 71319 71320
    Housing Black White

    →For boats up to 12m (Recreational Crafts)

    →Visible distance: 2 nm

    →12-15 V DC & 0.5W

    →White LED light

    →Deck Mounted

    →Last for 50.000 hours

    →Waterproof, non-corrosive, non-magnetic

    Included:

    1. Screw DIN7981 / ISO 7049 M3.5x32mm
    2. Wire length 0.6m
    3. Double-side adhesive sticker that can be used as drilling drawing

    *Weight: 55gr/pc

    Read moreDone

  • FOS LED 12

    0.00฿

    Bi-color Light Deck Mount

    Coding 71321 71322
    Housing Black White

    →For boats up to 12m (Recreational Crafts)

    →Visible distance: 1 nm

    →12-15 V DC & 1W

    →Red & Green LED light

    →Deck Mounted

    →Last for 50.000 hours

    →Waterproof, non-corrosive, non-magnetic

    Included:

    1. Screw DIN7981 / ISO 7049 M3.5x32mm
    2. Wire length 0.6m
    3. Double-side adhesive sticker that can be used as drilling drawing

    *Weight: 90gr/pc

    Read moreDone

  • FOS LED 12 & 20

    0.00฿

    All-Round Light 360°

    Code 71307 71308
    Housing Black White

    →For boats up to 20m (Recreational Crafts)

    →Visible distance: 2 nm

    →12-24 V DC & 1,5W

    →White LED light

    →Deck Mounted

    →Last for 50.000 hours

    →Waterproof, non-corrosive, non-magnetic

    Included:

    1. Screw DIN7981 / ISO 7049 M3.5x32mm
    2. Wire length 0.6m
    3. Double-side adhesive sticker that can be used as drilling drawing

    *Weight: 95gr/pc

    Read moreDone

  • FOS LED 12 & 20

    0.00฿

    All-Around Light 360°

    Code 71307 71308
    Housing Black White

    →For boats up to 20m (Recreational Crafts)

    →Visible distance: 2 nm

    →12-24 V DC & 1,5W

    →White LED light

    →Deck Mounted

    →Last for 50.000 hours

    →Waterproof, non-corrosive, non-magnetic

    Included:

    1. Screw DIN7981 / ISO 7049 M3.5x32mm
    2. Wire length 0.6m
    3. Double-side adhesive sticker that can be used as drilling drawing

    *Weight: 95gr/pc

    Read moreDone

  • FOS LED 20

    0.00฿

    Stern Light Side Mount 135°

    Code 71970 71971
    Housing Black White

    →For boats between 12-20m (Recreational Crafts)

    →Visible distance: 2 nm

    →12-24 V DC & 1.5 W

    →White LED light

    →Vertical Mounted

    →Last for 50.000 hours

    →Waterproof, non-corrosive, non-magnetic

    Included:

    1. Screw DIN7981 / ISO 7049 M4.2x32mm
    2. 1.2m length of wire per product,
    3. double-side adhesive sticker that can be used as drilling drawing

    *Weight: 165gr/pc

    Read moreDone

  • FOS LED 20

    0.00฿

    Masthead Light 225°

    Code 71972 71973
    Housing Black White

    →For boats between 12-20m (Recreational Crafts)

    →Visible distance: 3 nm

    →12-24 V DC & 3W

    →White LED light

    →Vertical Mounted

    →Last for 50.000 hours

    →Waterproof, non-corrosive, non-magnetic

    Included:

    1. Screw DIN7981 / ISO 7049 M4.2x32mm
    2. 1.2m length of wire per product
    3. double-side adhesive sticker that can be used as drilling drawing

    *Weight: 235gr/pc

    Read moreDone

  • FOS LED 20

    0.00฿

    Bi-color Light, Side Mount

    Code 71974 71975
    Housing Black White

    →For boats between 12-20m (Recreational Crafts)

    →Visible distance: 2 nm

    →12-24 V DC & 3W

    →Red & Green LED light

    →Vertical Mounted

    →Last for 50.000 hours

    →Waterproof, non-corrosive, non-magnetic

    Included:

    1. Screw DIN7981 / ISO 7049 M4.2x32mm
    2. 1.2m length of wire per product
    3. double-side adhesive sticker that can be used as drilling drawing

    *Weight: 235gr/pc

    Read moreDone
